Home/Packaging Material Equipment/Bottle blowing machine/PET/Semi-automatic/ horizontal strapping machine /

Weifang Sanjiang Glass Machinery Co., Ltd
ShanDong-WeiFang, Chinapacking size: Min.
1200(L) * 1000(W) * 1500(H)mm;
Max. :
1422(L) * 1118(W) * 2400(H) mm;
Notes:
1000mm and 1118mmis the width which the pallet comes into conveyor; 1000mm和1118mm
Max. weight:
1150kg;
Workshop interior temperature:
0-40℃;
Operating speed:
25 pallets/hour
strapping tensioning:
up to 230kgs;
strapping band:
width – 8-16mm; thickness – 0.65-0.70mm up to 0.85mm; Material: A2 PET strap;
joints sealing method:
heat-sealing;
sealing time:
1.2-2.3s(per to the tensioning of band);
tensioning speed:
0.6m/s;
band distribution and returning speed:
3.1m/s;
welding head moving speed:
0.21m/s;
installed power:
3kw;
voltage:
220v/380v, three phase;
band winding size:
inner diameter: 390mm; width: 150-160mm;
reducerSEW
inverterSiemens
electrical switchesGerman brand
pneumatic componentsAIRTIC
Plastic Drag ChainShanghai Wenyi
PLC control systemSIEMENS
strapping machine head.German TITAN
