Home/Filling Equipment/Bottle Filling/12 Head Servo Pump Filling Machine---JVS 12 HEAD, L-180/
JVS AUTOTECH INDIA PVT. LTD.
Ghaziabad, IndiaMODEL NO.
JVS 12 HEAD, L-180
Machine Direction
Left To Right (for Right To Left If Can Be Possible, On Customer Demand)
Machine Dimension
300mm (I) X 1100mm (w) X 1600mm (h)
Production Rate
160to 180 Bottles / Minute (depend On Filling Volume, Nature Of Liquid & Bottle /neck Sizes)
No of Filling Nozzles
12 Nos. With Adujstable Flow Control Vavle
Filling Mechanism
Servo Piston Filling
No of Alternate
Filling Rows 2 Nos
Power Characteristics
2kw 280 Vole, Single Phase A. C 50hz
Machine Filling Range
90 Lm To 760 MI
Filling Accuracy
+_1% Volume All Size
Change Parr
No Change Part Requied, Only Adjustable
Conveyor Length
12 Feet
Servo Motor
76 Watt.
Conveyor Motor
0.5 Hp (ab)
PLC& HMI Make
Panasonic / Delta Make / Fuji
Main AC Drive
2 Hp Three Phase (Bonfighlioll / Bharat Bijli ) For Servo Piston Filling It Will Be 3 Phase
Conveyor AC Drive
1 Hp Single Phase (Bonfighlioll / Bharat Bijli )
Level Filling
Level Filling System Also Available (Sensor Sick / System AB)
Storage
Storage Tank Capacity 200ltr With 15 Micro Filter
