Name


Specification

Mould plate

Mould plate material is P20 steel, Verticality: within 0.02mm

Parallelism: within 0.02mm

Core

Hardness:（HRC48-52）   Material:632

Built-in spiral cooling water shaft.

Cavity

Hardness:（HRC48-52）   Material:632

Four-axis machining of spiral cooling water shaft.

Screw neck

Hardness: (HRC46-48)      Material:S136

Special heat dissipation and positioning pin design improves the quality of the preform and the service life of the screw neck.

Needle valve

Hardness:（HRC59-61）  Japan brand

High strength, corrosion resistance,be able to work under high pressure.suitable for precise processing

Heat insulated cap

America DuPont brand, It is not easy to crack when disassembled. High durability

Heating ring

Voltage:240v          efficiency:268W

Famous Germany brand HOTSET, This brand uses advanced technology to prevent heat loss during mold use and halving energy consumption in production.

Nozzle

Hardness:（HRC38-40）

Material:Beryllium Copper

Famous America brand PCT, long service life, high durability.

Nozzle base

Hardness:（HRC59-61）

Material:SKD61

New type nozzle base.Ensure good precise heater transfer.

Heater strip

From Guangdong(adopt import heater strip)

Reducing elbow

Hardness:（HRC59-61）

Material:SKD61

Temperature controller

Guangdong brand, modular structure design, easy to disassemble, maintain and replace. It has multiple alarm modes, power off and couple off, sound and light alarm, leakage protection function, fully protect the heating element and thermocouple, safe and reliable

Graphite copper

Hardeness:(HRC30-32)

The graphite copper plate is to increase lubrication.

Water and air nozzle

Disassembly and maintenance are very convenient, which prolongs the service life of the mold.

Inner hexagon screw

Use domestic well-known brand, Pengchi 12.9 grade screws to extend the service life of the mold.
