Meidi 9QS-3600T Self-propelled Green Feed Harvester is a brand-newly designed high-end intelligent large-scale silage harvester, with a new main machine layout in which there is a large internal space for easier maintenance and caring; a header with a cutting width of 3.6m and a 480 HP engine are equipped for easy harvest of high-yield silage corn; the corn slicing and crushing effect can be on a par with imported machine by the new-type chopping hobbing cutter and grain crusher with a larger diameter; the spacious cab equipped with A/C make the working environment more comfortable; multi-functional armrest box and control handle can control the harvest working easily. 2024 Meidi Green Feed Harvester is trustworthy with advanced and reliable technology and excellent harvest quality.
Home/Agricultural machinery/Planting Machinery/Harvesting Machinery/9QS-3600T --- Self-propelled Green Forage Harvester/

China·Shijiazhuang Meidi Machinery Co., Ltd.
HeBei-ShiJiaZhuang, ChinaModel Name
9QS-3600T Self-propelled Green Forage Harvester
form
Self-propelled
Working state dimensions (length x width x height)
8010X3710X5870 mm
Matching engine rated power
353 kW
Matching engine rated speed
1900 r/min
Cutting width
3520 mm
Crop collecting header type
Straight cutting table
Header cutter type
Disc cutter
Feeding mechanism type
Feeding roller
Number of feeding mechanisms
4 indivual
Straw chopping mechanism type
Drum type
Grain crushing mechanism type
Roller type
Speed Shift
Manual speed shift
Drive mode
Hydraulic drive
Brake type
Disc
Steering wheel track
2110 mm
Guide wheel tire specifications
500/60-22.5
Driving wheel track
2400 mm
Driving wheel tire specifications
750/65R26
Wheelbase
2710 mm
Designed cutting length
1st gear: short 6; long 8 2nd gear: short 11; long 14 3rd gear: short 18; long 22 mm
