一、Upgraded Performance

1、DOUBLE STRONG PRESSURE LIFTER 360°PANORAMIC IMAGE

 Double strong pressure lifter, lifting force is increased by strengthening and thickening the lift cylinders, that makes suitable for lifting large implements with higher reliability and better stability.

 The 360°panoramic reversing image, ultra- wide viewing angle, and seamlessly spliced timely image information can help the driver understand the blind spots around the vehicle and help the driver park the vehicle more intuitively and safely.

2、MULTICHANNEL OUTPUT QUICK HITCH

 Equipped with 4 hydraulic outputs as standard, multiple outputs optional, with floating position and fixed position control, optional comprehensive force position control.

 Electric hydraulic lifter & Quick hitch are as standard configuration, which end ow the operation easily and high efficiency.

二、Advanced Technology

1、WATERPROOF AND DUST-PROOF CONNECTORS

 The whole vehicle harness is equipped with waterproof and dust- proof connectors to ensure the stable operation and reliability improvement of the electrical system.

2、REASONABLE PIPELINE LAYOUT

 The design of the pipeline direction is reasonable and the appearance is more beautiful.

3、LIFTING STEERING SHARING OIL SYSTEM

 Lifting and steering adopted a sharing oil system, independent hydraulic oil tank. The inlet and outlet oil pipes of lifting cylinder are connected directly with the advantage of fast lifting and falling, and the work efficiency is improved.

三、Strong Power

1、ENGINE

 Equipped with electronically controlled high- pressure common- rail engines, having advanced performance, strong power and high economic benefits. Power emission and performance upgraded, fuel consumption lower, reliability higher, and technology more advanced.

2、DRY AIR FILTER

 Weichai patented 93 dust filter is standard configuration, with good filtering effect and high cleanliness of the air intake system to avoid wear of the four accessories, filtering effect reaches 98%.

四、Comfortable Driving

1、AIR-CONDITIONING CAB

 Brond new closed air conditioning cab, having good tight ness and reversing image and GPS positioning system. The cab is raised as a whole and the vision of the whole machine is better.

2、SHOCK-ABSORBING LUXURY SEAT

 Equipped with shock- absorbing luxury seat, it can reduce the bumpy during operation and is comfortable to drive.

3、FULL LCD COMBINATION INSTRUMENT

 Equipped with a full LCD combination instrument , monitoring the working state of the whole vehicle at any time, more accurate data, more obvious function, and reliability improved.

五、Newly Upgraded Chassis

1、32F+32R SYNCHRONIZER SHUTTLE GEARBOX

 Adopting shuttle shift (32F+32R) composition mechanical stepped gearbox, reasonable gear matching and convenient speed and direction conversion, high strength, no broke teeth, low noise, more reliable.

2、ENLARGED BRAKES

 Enlarged strengthened brakes, high gear strengthen, good braking performance, safe driving and higher reliability.

六、Efficient Operation

1、LARGE STEETING ANGLE

 Steering angle up to 45°, turning radius less than 7m, turning time saved by 20%, working efficiently without loaving comers.

2、AUTOMATIC HOOD LOWERING LOCK

 The hood is easy to close and requires no effort. Only to gently pull the fixing wire to realize the hood automatically falling and locking.
