It is suitable for round bottles, square bottles, flat bottles, Conical bottle, alien bottles, and can achieve single labels, double sides label, three labels, one label full wrap around, positioning labels.

Dual human-machine interface: The main and auxiliary touch screens are linked and controlled, and the movable design of the auxiliary touch screen reduces personnel's back and forth movement during machine adjustment, making it easier to adjust and save machine adjustment time

Adopting ABB high-power, high torque, and ultra small inertia servo marking system, with high marking accuracy and stable operation

High speed label feeding station: composed of 3 servo motors, 1 variable frequency motor, dual cylinder clutch, and mechanical components.

1. Adopting a 3-pole support and 8-dimensional spatial adjustment design, it is easy to operate without the need for tools;

2. Diameter of label tray is increased to 500mm, with a floor standing independent bottom paper recycling mechanism that can accommodate 5-6 rolls of labels at once, reducing the number of label changes and cleaning of bottom paper

3. Pre delivery label servo control unwinding, pre discharge label hopper photoelectric induction scalar, independent label feeding motor, dual cylinder clutch tension control, coordinated with each other for label output, with an accuracy of ± 0.02mm and a speed of 160m/min;

4. The combination of three sets of aluminum alloy pressure rollers and power rubber rollers enhances the biting force, keeping the label in a tensioned state at all times for easy electric eye detection, thereby improving the accuracy of label printing. The label printing is smooth, while reducing the force on the label bottom paper and avoiding the phenomenon of broken bottom paper during high-speed label feeding;

5. Both the label and paper delivery adopt an airbag tensioning structure, which is simple and fast to operate without the need for tools, reducing the time for label replacement and cleaning the bottom paper.

Automatic switching during single labeling to achieve non-stop function for label changing, and adding label stations to achieve non-stop function for labeling double or triple labeling.

Automatic central centralized lubrication system.
