Precise Machinery Group Co.,Ltd
ShangHai, ChinaOther Description:
① The size specimens 3m brick flat pack input conveyor chain, excluding the discharge conveyor
②This specification does not contain carton printing device and adhesive tape devices
③Test machine sheet provided free of charge by the customer (the number of no less than one meter sizes 1 hour production)
Model:
PCP8000
Capacity:
Maximum 8000P / H (single input meter brick package, speed and packing specifications related)
Dimensions:
2200 × 1500 × 1900mm (excluding conveyor)
Weight:
about 1000KG
Applicable brick package:
250B(62×41×106.3mm)、250S(53×38×131mm)、200S(47×38×119.3mm)
Applicable straw:
U type, diameter ф4mm
Packing:
2 6 8 row row row -3 (available with handle)
Equipment Power:
3ф × 380V, 50Hz (voltage fluctuation within ± 5%), about 5.9KW
Air consumption:
VN = 500NL/min, 0.5Mpa, connection 3/8 "
Hot Melt Adhesive usage:
about 0.5g / box
Sheet basket capacity:
no handle about 200 (thickness 3mm time);About 80 (thickness 3mm time) when the handle
Input and output height:
920 ± 30mm
Environment:
below 1000m altitude, temperature 15-30 ℃, humidity 75% RH or less
