Manually place the aluminum can lid materials (in long paper packages, approximately 1100mm in length) neatly onto the conveyor mesh. The materials are conveyed forward and pass through the lifting and picking mechanism, which each time delivers one material to the peeling mechanism. The paper covering the material is automatically removed by the cutting tool. Then, the peeled aluminum lids are pushed into the auxiliary material bins in front (two in total, corresponding to two channels). Finally, the bins move laterally to transfer the aluminum lids to the corresponding left and right feeding troughs, and the feeding motor continuously supplies the aluminum lids to the capping machine behind.

[Equipment Advantages]

1. The top cover machine supplies the required easy-pull covers for the cans to the sealing machine, replacing the traditional manual top cover mode.
2. It automatically removes the paperboard and completes the paperboard recycling, continuously supplying covers to the can sealer at a maximum speed of 2,400 cans per minute.

3. The storage capacity of the reel is up to 40 rolls. The mesh chain storage bin is equipped with photoelectric detection to identify the right and wrong covers. When a wrong cover is encountered, the equipment will automatically alarm and stop.

4. Modular cap-feeding guide rails that can be freely connected or expanded as needed.

5. The control of actions such as feeding, peeling, and arranging materials is precise and reliable.

6. The roller spacing can be adjusted quickly, with high efficiency and convenient operation and maintenance.
