This series of densitometers is mainly designed for density measurement in the field of polymers. It is a classic product of the Dahometer brand, with excellent quality, high density accuracy, real-time display of density values, smooth and convenient operation, and time-saving features. It has better measurement stability and reliability and is suitable for high-requirement applications.

Wide Applications:

Polymers, plastics, rubber, wires and cables, composite materials, packaging materials, shoe materials, pipes, electrical appliances, sporting goods, tires, glass industry, rocks, ores, jewelry, crops, metal materials, automotive parts, new materials research laboratories, etc.

Product Compliance: Based on standards and specifications such as ASTM D792, ASTM D297, GB/T1033, GB/T2951, GB/T3850, GB/T533, HG4-1468, JIS K6268, ISO 2781, ISO 1183, etc.

Key Features:

The DIS function allows selection of a measurement method with memorized steps.

Product Advantages:

1. Uses imported German sensors for better measurement repeatability.

2. No-flip measuring frame for easier operation.

3. Waterproof membrane protects the internal components from water seepage.

4. PC material water tank, wear-resistant, drop-resistant, and corrosion-resistant.

5. 0.5cm stainless steel suspension cable, does not bend or deform, and remains perpendicular to the suspension rail without touching the water tank.

6. Can determine the percentage of the main material content in binary mixtures.

Other Functions:

1. Can measure any solid state.

2. Can measure floats, particles, powders, sheets, and wires.

3. Can use water as a medium, but other liquid media are also possible.

4. Features water temperature compensation.

5. Equipped with a windproof and dustproof cover, and a standard RS-232 communication interface.

6. Optional DE-40 printer for automatic printing of measurement results.

7. Suitable for field, laboratory, and other applications.

8. Three-year quality assurance service provided.

Technical Specifications:

Brand: DahoMeter

Model Product Number: DH-300

Weight: 300g

Weighing Accuracy: 0.01g/0.005g

Density Accuracy: 0.001 g/cm³

Density Range: 0.001~99.999g/cm³

Density Measuring Stand: ABS one-piece injection molded, flip-top-free measuring stand

Results Display: Density, Volume, Percentage Content

Measurement Type: Density of any solid form

Measuring Tank: Standard: One-piece injection molded professional transparent measuring tank (Dimensions: Length 15.3 cm × Width 10.7 cm × Height 9.3 cm)

Fixed Specifications: Water tanks of different sizes can be customized according to the dimensions of the measured product.

Parameter Settings: Water temperature setting, measured medium density setting, binary material mixing ratio

Standard Accessories: ① Main unit, ② Water tank, ③ Measuring platform, ④ Tweezers, ⑤ Thermometer, ⑥ Weights, ⑦ Windproof and dustproof cover, ⑧ One set of particle measuring accessories, ⑨ One set of float measuring accessories, ⑩ One power transformer

Power Supply Voltage: AC100V~240V 50HZ/60HZ (Default European standard plug, or select other national standard plugs)

Weight/Dimensions: 4.5kg / Length 42.5 cm × Width 17.5 cm × Height 32.5cm

Operating Steps:

1. With the display at 0.000g, place the product on the measuring platform. After the display stabilizes, press the ENTER key to memorize the value; the status symbol M1 will change to M2.

2. Place the product in the water. After the display stabilizes, press the ENTER key to memorize the value; the status symbol M2 will disappear, and the triangle symbol will point to the SG mark, indicating the density value.
