Efficient Energy Recovery: Braking energy recovery technology recovers and stores energy generated during braking, improving energy utilization.
Intelligent Control: Advanced control strategies are employed to achieve precise motor control, enhancing the performance of agricultural machinery.
Powerful Fault Diagnosis: Real-time monitoring of the electronic control system's operating status allows for timely detection and resolution of faults, ensuring safe and stable operation of agricultural machinery.
|
Type |
Rated power |
Rated input voltage |
Rated output current |
Short-time operating current/duration |
Cooling method |
|
YJMCU-336-30K |
30KW |
336V |
90A |
220A/30S |
Liquid Cooling |
|
YJMCU-336-40K |
40KW |
336V |
120A |
300A/30S |
Liquid Cooling |
|
YJMCU-336-55K |
55KW |
336V |
160A |
400A/30S |
Liquid Cooling |
|
YJMCU-540-50K |
50KW |
540V |
90A |
220A/60S |
Liquid Cooling |
|
YJMCU-540-60K |
60KW |
540V |
110A |
340A/60S |
Liquid Cooling |
|
YJMCU-650-160K |
160KW |
650V |
250A |
500A/10min |
Liquid Cooling |
|
YJMCU-650-220K |
220KW |
650V |
350A |
700A/10min |
Liquid Cooling |
|
YJMCU-650-315K |
315KW |
650V |
500A |
850A/10min |
Liquid Cooling |
|
YJMCU-072-05K |
5KW |
72V |
70A |
140A/30S |
Natural cooling |
|
YJMCU-096-10K |
10KW |
96V |
95A |
190A/30S |
Natural cooling |
|
YJMCU-096-15K |
15KW |
96V |
140A |
280A/30S |
Natural cooling |
