Jiangsu World Agricultural Machinery Co., Ltd.
JiangSu-ZhenJiang, China1: Adopting famous and high-quality engines, with sufficient reserve power, large torque and surging power.
Model
WD854A
Structure
4*4
Engine Power@speed(HP)
85
Engine Type
4 Cylinder, Inline, Vertical, Water-cooled, diesel engine
Fuel Tank Capacity(L)
170
Battery
12V
Air Cleaner
Dry
Gears
Shuttle 24F + 24R with Creeper
Clutch
13-inch double-acting
Brake
Mechanical disc
Differential Lock
Pin Type, Mechanical
Direction of turning
Clockwise,viewed from tractor rear
Diameter of PTO Shaft(mm)
35
PTO Speeds(rpm)
540/760/1000
3 Point Hitch
Category III &II
Control System
Position, Draft, Float
Rear Auxiliary Remote Valves
2 groups
Lifting Capacity(KG)
>=2190
Steering Hydraulic Power Steering
Dimension(mm) Canopy 4642*2050*2850
Ground Clearance(mm) 530
Tires(F/R) 13.6-24/16.9-34
Wheel Base (mm) 2250
Wheel Track (F/R)(mm) 1490,1555/1608,1500,1700
Ballast Weight Front/Rear(kg) 320/180
Min Operation Weight(kg) 3385
