◆ This machine is suitable for round bottles, square bottles, flat bottles, conical bottles, and special - shaped bottles, and can achieve single label, double - sided, triple label, one label full around, and positioning labeling.
◆ The pressure free servo bottle dividing star wheel is matched with the bottle feeding star wheel to prevent squeezing and scratching of the bottle body, ensuring smooth and stable product entry and exit during high - speed operation.
◆ Dual human - machine interface: The main and auxiliary touch screens are linked and controlled, and the movable design of the auxiliary touch screen reduces personnel's back and forth movement during machine adjustment, making it easier to adjust and save machine adjustment time.
◆ Using BASLER cameras from Germany to collect positioning points and coordinate with servo station motors, precise positioning and labeling are achieved through PLC system control.
◆ Adopting ABB high - power, high torque, and ultra - small inertia servo marking system, the marking speed can reach 80m/min.
◆ Dual standard seat 4 - standard station automatic switching for use, achieving non - stop function for changing standards.
◆ Label feeder: Three column structure, 8 - dimensional space adjustment, independent servo motor and three - level spring clutch cooperate to control label delivery, independent servo motor and mechanical buffer cooperate to recover the bottom paper, with even force and not easy to break the bottom paper.
◆ Automatic central centralized lubrication system, regularly lubricate the main operating parts, facilitate maintenance and extend service life.
◆ Automatic central centralized lubrication system
