Vacuum Chamber machines or Vacuum packing machines are used to evacuate the air around perishable goods such as food products like cheese and meat whose extension of shelf life is desired. Vacuum Chamber machines or vacuum sealers remove the air from the package at the same time sealing it, delivering the ultimate in protection while extending the distribution life and maintaining product integrity.
Vacuum sealers or Vacuum chamber machines commonly use vacuum bags or barrier pouches. These barrier bags provide a barrier against the atmosphere and moisture. The bags are placed in the chamber, the desired amount of air is extracted from the vacuum bag and then sealed. All of Get packed Vacuum Chamber machines are made from stainless steel and are available in a variety of sizes and configurations such as the option of gas flushing kits.
Home/Filling Equipment/Can Filling/Fully Automatic Linear Paper (Plastic) Cup Filling and Sealing Machine YS-ZDZK-320R/

Hangzhou Youngsun Intelligent Equipment Co., Ltd.
ZheJiang-HangZhou, ChinaModel type
YS-ZDZK-320R
Upper film width
293mm
Lower film width
322mm
Upper film thickness
0.08-0.12mm
Lower film thickness
01.2-0.3mm
Upper film roll outer dia
250mm
Lower film roll outer dia.
350mm
upper film roll core shaft dia.
76mm(3")
ower film roll core shaft dia.
76mm(3")
working speed
200-400cycle/h
Total power
12Kw
Heating power
8Kw
Compressed air pressure
≥ 0.6Mpa
Air consumption
0.8-1m³/min
Vacuum capability
100m³/h
Vacuum degree
≤200Pa
Power
380V,50HZ,3P5H
Machine size
4500×1030×1900
Weight
1500Kg
Product Description
Technical Parameter
