Product Name:
intelligent electromagnetic flowmeter
product model:
kld-dn15 ~ DN1200
measuring medium:
conductive liquid
connection mode:
flange connection, simple plug-in
measurement accuracy:
± 0.5% R, ± 1%
nominal pressure:
dn15-dn300, PN < 1.6Mpa; DN350-DN800,PN<1.0MPa; Above dn900, PN < 0.6MPa;
structural form:
one type: IP65, split type: IP65, IP68
lining material:
neoprene, polytetrafluoroethylene, polyethylene
MediumNo impurities, no corrosive gas, natural gas, etc
Acuracy+1.5%, +1.0%, +0.5%
RepeatabilityBetter than 0.1%
Flow range6.5~6500m3/h
Display cotentInstantaneous working conditions, volume, total standard volume, temperature,pressure, battery capacity, etc.
Measurement diameterDN50~DN300
Connection typeFlange connection
Power supplyRun on battery or external power supply
Output supplyPulse signal output, 4-20mA current signal output, RS485 communication and GPRS
