AD25 dispersing homogenizer is driven by a high-speed motor and is suitable for mixing low to medium and high viscosity liquids or distributing materials in liquid media, breaking tissue cells, etc. The integrated structure of drive output and working head positioning makes the operation state more stable; the working head is made of high-quality stainless steel, and the experimental application area is wide; the operating speed is controlled by microprocessor, which can instantly compensate for the speed changes caused by load changes and power supply fluctuations, and the constant speed is reliable; built-in soft start and automatic overload protection ensure the safety of continuous operation of the experiment at full load for a certain period of time; the speed is infinitely adjustable to meet the experiment's need to correct the operating speed at any time. The digital display speed is intuitive, and the experimental data collection is convenient; the operation timing control ensures effective control of the experimental time.
Home/Laboratory Equipment/Organic Matter Inspection/High shear dispersing emulsifier AD25/

Shanghai Angni Instruments & Meters Co.,Ltd.
ShangHai, ChinaRated voltage
AC220±10% V
Rated frequency
50/60 Hz
Input power
950 W
Output power
570 W
Rated torque
1.95 N.m
Working mode
S1 (continuous)
Operation control mode
Combined control knob
Speed adjustment range (no load)
1000~28000 rpm
Speed control type
Stepless
Working head maximum torque
190 N.cm
Working head material
SS316L (stainless steel)
Adaptive working head (optional)
20 G/F, 25G/F, 30G/F
Allowable ambient temperature
Not more than 40 ℃
Allowable relative humidity
Not more than 80 %
dimensions
215×310×720 mm
Weight
9KG
Remarks
The characteristics of the drive motor are that the speed and torque are in direct proportion, and the higher the speed, the greater the torque.
