High-Temperature Optical Contact Angle Meter HTC1700
The HTC1700 High-Temperature Optical Contact Angle Meter is independently developed, designed, and manufactured by Betop Science. It utilizes optical imaging principles to capture high-definition images with a high-resolution, high-speed industrial camera under high-temperature conditions. The instrument then processes these images through proprietary software to accurately calculate and fit the data.
It is capable of measuring the surface contact angle and wettability between samples and substrates. The instrument features a software-controlled temperature module with 30-stage programmable temperature control, making it a comprehensive tool. Its ergonomic design provides user-friendly automation for sample injection, stage adjustment, and optical system regulation, ensuring precise and efficient testing.
Instrument Features
-
Temperature Options: 2300°C, 1700°C, 1200°C, with 30-stage programmable temperature control.
-
Contact Angle Measurement Range: 0–180°, with a precision of 0.1°.
-
Atmosphere Options: Compatible with inert gas (argon, nitrogen, etc.) protection or high vacuum (1×10<sup>−3</sup> Pa) environments.
-
High-Speed, High-Resolution Industrial Camera: Capable of capturing images at a rate of ≥220 frames per second for continuous image recording.
-
Intelligent Image Analysis and Data Processing Software: Automatically and continuously calculates the contact angle θ of high-temperature melts.
-
470 nm Blue Light Source: With continuously adjustable brightness.
-
Integrated Design: Ergonomically optimized for user convenience.
Main Functions
-
Static and Dynamic Contact Angle Measurement: Capable of measuring liquid/solid contact angles statically and dynamically analyzing the changes in contact angle over time or with temperature.
-
Surface Tension Calculation: By obtaining relevant parameters, it can calculate the surface tension of melts and assess their wettability on substrate materials.
-
Material Parameter Measurement: Can measure parameters of certain solid materials (such as sintering temperature, softening temperature, melting point, etc.).
-
Sample Morphology Monitoring: Records changes in the shape of samples during the sintering process.
-
Wide Temperature Range Measurement: Enables measurement of the above parameters within the temperature range of room temperature to 2200°C. With 30-stage programmable settings, it can analyze complex heat treatment processes.
