Energy- saving hot fluorine unit mobile phone remote control, 485 communication Intelligent "heart" technology Control the operation of cold storage at any time
◉ Danfoss Electronic expansion valve throttling
◉ System design, multiple protection
◉ Hot fluorinated cream, save electricity and worry
◉ Liquid crystal display, accurate temperature control
◉ automatic alarm, screen intuitive
◉ Wechat program, transportation control
◉ Air conditioning installation, convenient and simple
Name specification
LTYT-15HP
Head type
Copeland ZF49/ ZB14
Heat transfer area (㎡)
150
Power (W)
9000
Temperature range
-30~10℃
Use space
100-240m³
Overall dimension: Length X width X height(mm)
1340X760X910
Mounting dimension (mm)
870X725
Supporting motor fans
:
Fan diameter (mm)
500
Motor (W)
420X2
Air volume(m³/h)
6550X2
remark
Compressor brands can be according to selected customer needs
