Features:
Intelligent Safety:
PES three-level adjustment, multiple performance modes, allowing for flexible selection in complex working conditions: OPS protection; hydraulic pipe burst protection, forward tilt self-locking protection; multiple electrical protections (short circuit protection, overheat protection, low battery protection, sequential protection); parking safety reminder, slow rollover reminder on slopes.
Comfort and Energy Saving:
Full LED lighting, high brightness, long lifespan, and energy saving; wide-view mast, providing a wider working field of vision and enhanced safety; standard loading handle, optional reversing horn handle; standard small-diameter steering wheel with ball handle for more comfortable steering; spacious and comfortable seat with ample legroom, effectively reducing driver fatigue; optional USB power interface for convenient phone charging.
Stable and efficient:
The integrated brake hub and half-shaft oil seal structure are optimized; the one-piece cast drive axle offers high strength, greater reliability, and a longer service life; the high-ratio reduction gearbox is more efficient. The cast steering axle provides a large turning angle, a small turning radius, and is reliable and durable. Reinforced and optimized wheel rims enhance robustness and durability; the gantry upper beam frame structure ensures reasonable stress distribution, improving rigidity and strength. The application of a composite roller design improves the lateral installation control accuracy of the cargo rack.
| odel | Unit | CPD20 | CPD25 | CPD30 | CPD35 | CPD38 | ||||||||||
| Configuration No. | A5LiK2-H | A6LiK2-M | A6LiK2-S | A5LiK2-H | A6LiK2-M | A6LiK2-S | A5LiK2-H | A6LiK2-M | A6LiK2-S | A5LiK2-H | A6LiK2-M | A6LiK2-S | A5LiK2-H | A6LiK2-M | A6LiK2-S | |
| Rated lifting capacity | kg | 2000 | 2500 | 3000 | 3500 | 3800 | ||||||||||
| Load center distance | mm | 500 | 500 | 500 | 500 | 500 | ||||||||||
| Standard mast lifting height | mm | 3000 | 3000 | 3000 | 3000 | 3000 | ||||||||||
| Total length (without fork) | mm | 2540 | 2610 | 2792 | 2798 | 2800 | ||||||||||
| Total width | mm | 1160 | 1160 | 1225 | 1225 | 1225 | ||||||||||
| Gradeability, full load | % | 18 | 14 | 12 | 18 | 14 | 12 | 18 | 14 | 12 | 18 | 14 | 12 | 17 | 13 | 12 |
