Performance and characteristics

1、The continuous rotating preform loading system is closely combined with the machine, which effectively reduces the occupied area. The preform mouth is upward with simple structure.

2、The continuous heating system, the preform heating pitch is 38mm, which effectively utilizes the heating space of the lamp tube and improves the heating efficiency and energy saving effect of the preforms (energy saving can reach 50%).

3、Constant temperature heating oven, ensure the surface and internal of each preform is heated evenly. The heating oven can be overturned, easy to replace and maintain the heating lamp.

4、The preform transfer system with grippers, and the variable pitch system are both driven by the servo motors, ensure high speed revolving and accurate positioning.

5、The servo motor drive molding mechanism, triggering off the linkage to the bottom mold, the application of high speed precision blowing valve unit helps to make high capacity.

6、The cooling system for the preform neck is equipped to ensure the preform neck does not deform during heating and blowing.

7、The high pressure blowing system is equipped with air recycling device which may reduce air consumption to achieve the energy saving efficiency. (Energy saving can reach 30%).

8、Being highly intelligent, the machine is equipped with units of preform temperature detection, leaking bottle detection and rejection as well as jammed air conveyor detection, etc, which ensures the machine work efficiently and stably.

9、Operation on the touch screen is simple and easy.

10、This series is widely used for making PET large volume container, such as drinking water, edible oil, foodstuff and daily chemical.
