Home/Agricultural machinery/Aquacultural Machinery/Multifunctional fertilizer spreader--- Xingyueshen XY377-A/
Xingyue Group Co., Ltd.
ZheJiang-JinHua, ChinaModel
Xingyueshen XY377-A
Structural form
Inline 3-cylinder water-cooled 4-stroke
Total displacement gas volume(cc)
1132
Power (kW)/Speed (r/min)
18/3000
Power output shaft connection dimensions
：
Spline have effect length(mm)
55.5
Major diameter of splineD(mm)
35
Spline minor diameterd(mm)
27.5
Key width(mm)
8
Number of teeth Z
6
Power output speed(r/min)
360~720
Power output rotation direction
Clockwise (looking forward from the rear axle)
Fertilizer spreading department
：
product name
Disc centrifugal fertilizer spreader
structural style
Self moving square hopper structure
Operation mode
Backward throwing
Overall dimensions(Length * width * height)(mm)
1160*680*990
Bin volume(L)
240
Payload(kg)
:200
Type of throwing device
Rear mounted single disc spreading
Fertilizer conveying method
Misfeeding during mixing
Job width (ground clearance of 70cm)(m)
≤30
Spreading rate(kg/min)
≤60
Work efficiency(h㎡/h)(Mu/hour)
5.3-8.6(80-130)
Fertilizer type
Solid granular fertilizer
