Home/Agricultural machinery/Aquacultural Machinery/Multifunctional machine spray machine --- Xingyueshen XY377-A/
Xingyue Group Co., Ltd.
ZheJiang-JinHua, ChinaModel
Xingyueshen XY377-A
Structural form
Inline 3-cylinder water-cooled 4-stroke
Total displacement gas volume(cc)
1132
Power (kW)/Speed (r/min)
18/3000
Power output shaft connection dimensions
：
Spline have effect length(mm)
55.5
Major diameter of splineD(mm)
35
Spline minor diameterd(mm)
27.5
Key width(mm)
8
Number of teeth Z
6
Power output speed(r/min)
360~720
Power output rotation direction
Clockwise (looking forward from the rear axle)
Spraying Department
：
Spray amplitude(m)
10
Spray lever lifting control
Electric hydraulic lifting
Liquid pump type
diaphragm pump
maximum working pressure(Mpa)
3
Liquid pump flow rate(m³/h)
≤80
Water absorption height(m)
≤3
Spray nozzle type
Domestic fan-shaped nozzle
Medicine box capacity(L)
200
operating pressure at sprinkler(Mpa)
0.2-0.6
Number of nozzles
16
Nozzle spacing(cm)
60
Atomization angle
110°
Work efficiency(h㎡/h)(Mu/hour)
3.9-5.9(60-90)
