• Reduced Investment

• High Efficiency & Flexibility

• Safety & Reliability

• 3 "S" Integrated System Design: Pre-installed and pre-commissioned to minimize on-site commissioning work

• Innovative AI Bionic Thermal Balance: Reduces the system's all-day heat dissipation loss by 33%

• Liquid-Cooled Uniform Heat Dissipation: Ensures a performance lifespan of 12 years

DC Side Parameters

:

Cell Type

LFP 3.2 V / 314 Ah

System Battery Configuration

256S1P

Battery Capacity:

257 kWh

Battery Voltage Range

691.2 V - 934.4 V

AC Side Parameters

:

Rated Power:

125 kW

Total Current Waveform Distortion

< 3 % (at rated power)

DC Component

< 0.5 % (at rated power)

Rated Grid Voltage

380 V

Grid Voltage Range

323 V - 418 V

Rated Grid Frequency

50 Hz

Grid Frequency Range

45 Hz - 55 Hz

System Parameters :

Cabinet Dimensions (Width * Height * Depth) -

Weight 2900 kg

Maximum Cycle Efficiency 90%

Protection Class IP55

Auxiliary Power Supply Self - supply/External supply

Corrosion Resistance Class C3 / C5

Operating Humidity Range 0 % - 100 % (no condensation)

Operating Temperature Range - 30 °C - 50 °C (> 45 °C with derating)

Maximum Operating Altitude 3000 m

Battery Cabinet Cooling Method Intelligent Liquid Cooling

Fire Safety Configuration Composite Detector, Aerosol, Immersion Water Fire Protection (Optional)

Communication Ethernet

Communication Protocol Modbus TCP

Compliance Standards GB/T 36276, GB/T 34131, GB/T 34120, GB/T 34133
