SV-3576AB6
Rockchip RK3576 processer, 2*GbE LAN, 10*USB, 6*COM, 1*HDMI, 1*eDP, 1*LVDS/eDP
- Useing Rockchip RK3576 Prosesser
- 8G Memory On Board,64G eMMC Storage
- 2*GbE LAN, 10*USB, 6*COM
- 1*M.2, BT+WiFi Module
- 1*HDMl, 1*LVDS/eDP, 1*eDP
- 3.5'', DC 12V
Home/Accessories/Consumables/Electrical/Servo system/Rockchip---SV-3576AB6/
Shenzhen Seavo Technology Co.,Ltd.
, ChinaGeneral
:
CPU
ARM Rockchip® RK3576, Quad-core Cortex-A72 +;Quad-core Cortex-A53, up to 2.2GHz
Memory
8GB SDRAM LPDDR5 Memory Down on board
Storage
64GB eMMC5.1 on board
Expansion
1*Mini-PCIe (4G supported);1*M.2 (Key-B, PCIe/USB 3.0/SATA, 2242/3052
BIOS
AMI UEFI BIOS
OS
Android 14,Linux
I/O Interface
:
Ethernet
2*Realtek® RTL8211F FE Ethernet Controller, RJ45
Serial
4*RS232,2*RS232/485
USB
4*USB 3.0,6*USB 2.0
Audio
Everest®Codec,;with MlC+Line-out and Amplifier
GPIO
8*Programmable GPIO
Display:
Display Interface1*HDMI,1*LVDS/eDP,1*eDP
Multiple DisplayTriple
Mechanical & Environment :
Dimension146*105mm
Power InputDC 12V
TemperatureOperation: 0℃~60℃, Storage: -40℃~85℃
Relative Humidity5%~95%, non-condensing
Product Description
Technical Parameter
Configuration List
