1. Equipment Composition

A. Main Machine

• Siemens Programmable Logic Controller (Germany)
• Delta Motion Controller System (Taiwan, China)
• Siemens 10-inch color screen HMI (Germany)
• Boxin High-speed Response Deviation Correction System
• Schneider 750W High-speed Label Feeding Servo Motor (France)
• Schneider 1500W High-speed Self-rotating Servo Motor (France)
• Delta High-speed Motion Servo Amplifier (Taiwan, China)
• Panasonic Color Mark Sensor (Japan)
• Nemicon High-resolution Encoder (Japan)
• SICK Product Detection Photoelectric Switch (Germany)
• Timed Power-On Heating Module

B. Mechanical Part

• Main Machine Conveying Mechanism: 2200W TRANSTECNO AC motor (Italy) (equipped with TRANSTECNO reducer), with inverter speed regulation.
• Gluing Mechanism: Panasonic inverter motor + precision gear pump
• Bottle Separating Mechanism: Industrial screw-type bottle separating mechanism
• Bottle Feeding Mechanism: Cooperates with the screw-type bottle separating mechanism and star wheel positioning feeding mechanism to ensure the accuracy and stability of feeding.
• Labeling Mechanism: Rotary turntable drives the bottle for labeling during rotation.
• Label Pressing Mechanism: Silicone plate + Teflon cloth combination
• Bottle Guiding Mechanism: Profile guide rail with two-coordinate adjustment

2. Equipment Safety Protection Section

• Label Lack Alarm: Triggers an alarm when the label is about to run out to remind the operator to prepare for label replacement.
• Missing Labeling Alarm: Facilitates the control of labeling quality.
• Air Pressure Detection: Stops the equipment for protection when the air pressure fails to meet the equipment production requirements, preventing the generation of defective products.
• Temperature Detection: Stops the equipment for protection when the temperature of the hot melt adhesive fails to meet the equipment production requirements, preventing the generation of defective products.
• Label Joint Detection: Automatically stops the equipment for protection when a label joint is detected.
