General Basic Specifications of SV630 Servo Drive

Basic Specifications

• Control Mode: IGBT PWM control, sinusoidal current drive method. For 220V and 380V, single - phase or three - phase full - wave rectification is adopted.
• Encoder Feedback: 18 - bit multi - turn absolute encoder (can be used as an incremental encoder without a battery).
• Operating/Storage Temperature^[1]:
  • Operating/Storage Temperature: 0°C - 55°C. When the ambient temperature is between 45°C - 55°C, the average load rate should not exceed 80% (no icing); - 20°C - + 70°C.
• Operating Humidity: Below 90% RH (no condensation).
• Vibration Resistance/Shock Resistance: Vibration Resistance: 4.9m/s²; Shock Resistance: 19.6m/s².
• Protection Class: IP20.
• Pollution Degree: PD2.
• Altitude:
  • Maximum altitude up to 2000m. No derating is required for use at 1000m and below. For every 100m increase in altitude above 1000m, the derating is 1%. If the altitude exceeds 2000m, please contact the manufacturer.

Note

Digital Input Signals - Input Signal Function Selection

• 7 channels of DI. The maximum frequency of DI1 - DI5 digital signal input is 1kHz (will decrease when the current - limiting resistor is greater than 2.4kΩ). The hardware delay of DI8 - DI9 digital signal input is less than 1ms (current - limiting resistor is 2.4kΩ).
• DI functions include: Servo enable, alarm reset, gain switching, command switching, mode switching, zero position fixed value, position command prohibition, pulse command selection, positive direction over - travel, reverse over - travel, speed limit, torque limit, positive and negative direction movement, step - by - step enable, handwheel, set current position as origin, set direction, set current position as origin, emergency stop, multi - segment position, interruption determination, axis control command, position deviation elimination, positioning and command completion signal clearing, etc.

Digital Output Signals - Output Signal Function Selection

• 5 channels of DO. The load capacity of DO is 50mA, and the voltage range is 5V - 30V.
• DO functions include: Servo ready, motor rotation signal, zero speed signal, speed consistency, speed arrival, torque arrival, positioning completion, positioning approach, torque limit, speed limit, gate, alarm output, fault output, alarm or fault output, interruption determination completion, origin return completion, enable completion, internal command completion, allow writing next segment command, internal movement completion, etc.

Over - travel (OT) Prevention Function

Electronic Gear Ratio

Protection Functions

LED Display Function

Vibration Suppression Function

Usability Functions

Communication Functions - Background Debugging

Communication Functions - Multi - station Communication Protocol

Communication Functions - Number of Multi - station Communication Axes

Communication Functions - Axis Address Setting

Communication Functions - Functions

Others
