I. Overview
The T24 temperature and pressure integrated transmitter adopts an integrated structure design of temperature and pressure transmitters, simultaneously measuring the temperature and pressure of the medium being tested, and outputting two standard 4-20mA current signals for temperature and pressure respectively. This transmitter unifies the temperature and pressure sensitive elements at the front, collecting the dynamic changes in temperature and pressure of the medium in real-time, with high measurement frequency response and good stability. It features a compact all-stainless steel design, with permanent laser marking of product information, and supports customization needs such as IP68 submersible types.
II. Product Features
-
Measurement Range: Pressure range: -0.1 to 15MPa standard, Temperature range: -20°C to 80°C standard;
-
Integrated structure design allows for the measurement of two types of signals in one installation;
-
Unifying the temperature and pressure sensitive elements at the front results in high measurement frequency response and good stability;
-
Supports IP68 submersible customization and other customer-specific customization needs.
