Working Principle:
The bimetallic steam trap operates based on the temperature difference between saturated steam and discharged condensate. It continuously discharges condensate once the set temperature is reached.

Product Features:
- Valve body and bonnet are made of forged steel A105.
- Valve disc and seat use special stainless steel with heat treatment; disc hardness reaches HRC55 for extended service life.
- Imported bimetallic elements ensure precise temperature control.
- Closing system utilizes a high-precision linear sealing structure.
- Built-in strainer ensures the trap operates in a clean environment.
- Back pressure rate is up to 50% or more.

Available Configurations:
- Connection Method: Threaded / Welded

Highlights: Bimetallic Control, HRC55 Disc, Built-in Strainer
