Features:
- It is specially designed for high speed packing requirement of bottled drinking water (pure water, beverage, juice, milk ect.)
- When conveying the bottles, it can arrange and film wrap the bottles automatically, which save the time and improve the working efficiency.
- PLC control, automatic work processing.
- Constant temperature cutting blaes, which surface sprayed by Teflon, with the advantage of stable sealing.
- Touch screen is used to ensure easy operation.
- Suit for different bottle size and packaging type without tray packing.
- This type of shrink wrappig machine is your best choice for middle capacity, which is easy operation and maintance.
|
Facility model |
WD-350B type |
|
Facility overall size |
L14000×W1200×H2100mm |
|
Main equipment |
3400×1250×2350mm |
|
Shrinkage machine |
4200×1200×1700mm |
|
Conveyor |
5200×1300×950mm |
|
Wrappage max size |
L2400×W650×H450mm |
|
shrinkage film material |
PE |
|
shrinkage film thickenss |
0.08mm |
|
thermo shrinkage tunnel max temperature |
160 - 260° adjust at will |
|
max output per minute |
30-40 bag |
|
facility power |
35Kw |
|
actual power |
30Kw/h |
|
pressure requirement |
380V/50-60HZ |
|
facility weight |
2800 |
|
air pressure |
0.6-0.8mpa |
|
working noise |
≤65db |
|
import bottle convey belt width |
541mm |
|
fan |
1.1Kw 3set 380V, 60W 6set 380V |
