Product Features:

Key components are all from leading brands: They determine the equipment's stable performance, cutting accuracy, and maintenance efficiency.

1. Servo Motor Brand: Delta (Taiwan)

2. Servo Motor: Delta (Taiwan)

3. Contactor: Siemens (Germany) or Shihlin (Taiwan)

4. Touch Screen: Delta (Taiwan)

5. Servo Motor: Delta (Taiwan)

6. Inverter: Delta (Taiwan)

7. Relay: Omron (Japan)

8. Blade: Special high-end material: 440C or 440 stainless steel, refined through over a dozen processes, including

precision heat treatment, quenching, high-temperature tempering, heat preservation, and grinding.

9. Blade Features: High hardness (56-61 degrees), sharp and durable, corrosion-resistant, and strong toughness.

10. Conveyor Belt: German brand, high-friction, food-grade conveyor belt.

11. Designed with electrical protection terminals to automatically protect against electrical burnout in the event of

incorrect power connection or phase loss.

Key plate components determine the equipment's service life and compliance with food hygiene and safety

requirements (the Food and Drug Administration has clear documentation regarding food processing materials).

1. The machine's plate, frame, motor base, and reinforcements are all made of SUS304 stainless steel.

2. Motor main plate thickness: 20mm 304 stainless steel; reinforcement thickness: 30mm 304 stainless steel.

3. The motor main plate and reinforcements are CNC-machined, significantly enhancing the equipment's precision,

stability, and durability.

4. The upper conveyor belt is composed of a stainless steel pneumatic spring and synchronous conveyor belt, ensuring

 stable feeding and preventing slippage.

5. The casters are all high-standard: 304 stainless steel silent, load-bearing brake casters that rust-proof and significantly

reduce vibration.

Convenient, streamlined, visual, and user-friendly operation:

1. Adjustable cutting size: Digitally adjustable via the touchscreen.

2. The conveyor can be quickly disassembled for easy cleaning.

3. Excellent cutting quality: Smooth cut surfaces and smooth slices.

4. Customizable, neatly arranged product discharge facilitates the next production process, improves yield, and saves

labor.

5. Nylon residue will not fall into the food during cutting, preventing food safety issues.

6. An automatic oiling system is designed. If oil is low, an alarm will automatically alert you to refill, preventing damage to

the equipment due to lack of oil in the shaft.
