The JICHAI series units are powered by the 190 series high-power diesel engines produced by China National Petroleum Corporation Jinan Diesel Power Plant, coupled with our company's HD series high-power generators, providing users with stable, efficient, and convenient power protection to effectively meet the needs of user load power.
-
This series of units has very high stability and excellent cold start effect.
-
Good water cooling system, part of the single motor unit cooling water tank. Excellent and effective way to supply machinery, electronic instruments, to ensure that the unit's operation is always stable. The power has multiple protection systems, such as overspeed protection, low oil pressure protection.
-
The economic base of diesel-specific work steel, high-power unit base supporting professional design, greatly improving the level of stability and reliability of plant operation.
-
The full range of units with 24V electric start, coupled with our expertise with high-performance lead-acid batteries to ensure the unit's instantaneous starting current, to ensure the success rate of the ignition unit.
-
Jinan Diesel specific set of technologies, reasonable arrangements for unit operation, easy to operate and observe the operation.
-
Suitable for fixed load power generation, may also have optional custom mobile, low-noise type units, is your choice of high-power load standby power when the best choice.
-
Service stations across the country, allowing you to use no worries. Military technology, allowing you to use with confidence.
Home/Public Equipment/Zhongjie-JICHAI Series Diesel Generator Sets/

Jiangsu Zhongjie Power Equipment Co., Ltd.
JiangSu-YangZhou, ChinaUnit Model
ZJ-500
Power (kW)
500
Current (A)
6800
Unit Dimensions (L×W×H) (mm)
5270×1970×2600
Engine Model
G6190ZLC
Power (kW)
540
Cylinders
6
Bore*Stroke (mm)
190/210
Fuel Consumption Rate (g/kW.h)
≤208
Oil Capacity (L)
140
Product Description
Technical Parameter
