◆ This machine is suitable for opp hot melt labeling of cylindrical containers with large capacity, such as round bottle, square bottle, flat bottle, and oval bottle.
◆ The label printing pattern will not deform to ensure the aesthetic appearance of the product's outer packaging and greatly reduce packaging material costs.
◆ The Chinese and English touch controlled continuously variable speed system is easy to operate. When adjusting, only the production capacity needs to be set on the human - machine interface. The speed parameters such as conveying, screw, and bottle inlet and outlet star wheels can be changed simultaneously, without the need for individual adjustment of each part.
◆ Adopting German BECKHOFF PLC control and servo motor system ABB brand from Switzerland, high - power, high torque, and ultra small inertia servo marking system, making our machine's operation more simple, stable, and reliable.
◆ High speed label feeding stations:

1. The unwinding, label feeding, and drum are all controlled by independent servo, and the automatic corrector is matched: the cutting accuracy is 1mm, the tilt angle is ≤ 1°, and the label feeding accuracy is ± 0.3mm

2. The cutting blade is made of imported materials that are resistant to high temperatures and wear. The independently developed blade drum adopts a constant temperature cooling method, which ensures that the cutting blade does not generate heat during high - speed operation and extends its service life

3. Adopting honeycomb rubber rollers and roller gluing method, the amount of glue can be adjusted in thickness and thickness, with a coating thickness of 1.2 - 1.6 threads, which can save glue. (Glue consumption: about 80000pcs labels per kg glue);

   ◆ Automatic central centralized lubrication system
